(888) 312-8812 Login SignupMagnum Suspension Shock Absorber
| Lower Mount Code | LS54 |
| Upper Mount Code | LS54 |
| Dust Shield Included | Yes |
| Part Description | Shock Absorber |
| Compressed Length | 15.66 IN |
| Extended Length | 25.4 in |
| Gas Charged | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 3/4" Sleeve ID X 1.3/4" Sleeve OAL |
| Parts Pack(s) | None |
| Travel Length | 9.74 in |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 3/4" Sleeve ID X 1.3/4" Sleeve OAL |
| Compressed Length | 397.8 MM |
| Extended Length | 645.2 MM |
| Travel Length | 247.4 MM |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
| MSDS Sheet Number | 1164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708801600 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598210449 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
| Brand | Part Number |
|---|---|
| Hino | 48530E0100, 60670014, 60670019, 4.853e104, 48530E0390, 48530E0290 |
| OEM | 60670019, 4.853e104, 60670014 |
| Gabriel | 83166 |
| Hendrickson | 6067019, 60670014, 60670014L, 60670019, 60670019L, 60670029L, 60670031L |
| NAPA Shocks | 66455 |
| Gold Shock Absorber | 5001259 |
| PRT HD | 925063 |
We have 5 alternatives for the 66455 by MONROE:
