LUK LFW302 Part Description
Manufacturer
Product Description
LuK Rigid Flywheel
Application Summary
Dodge Ram 2500 1994-2003 (L6, 5.9L), Dodge Ram 3500 1994-2005 (L6, 5.9L)
Flywheel
LUK LFW302 Specifications
Product Attributes
| Ring Gear Thickness | 0.563 inch |
| Ring Gear Thickness | 14.3 mm |
| Ring Gear Chamfer Side | Engine |
| Dowel hole diameter | 0.3135 inch |
| Dowel hole diameter | 7.963 mm |
| Bolt hole PCD crankshaft | 4.3307 inch |
| Bolt hole PCD crankshaft | 110 mm |
| Flywheel friction surface outer diameter | 12.9921 inch |
| Flywheel friction surface outer diameter | 330 mm |
| Ring Gear Chamfer Position @ 6:00 O´clock | Left |
| I.D. for Pilot | 1 inch |
| I.D. for Pilot | 25.4 mm |
| Dowel Hole Pattern | 3 |
| Flange Thickness | 0.6398 inch |
| Flange Thickness | 16.25 MM |
| Flywheel Thickness [mm] | 1.6693 inch |
| Flywheel Thickness [mm] | 42.4 mm |
| Ring Gear Mounting O.D. | 14.403 inch |
| Ring Gear Mounting O.D. | 365.836 mm |
| Bolt hole PCD clutch pres.plte | 14.126 inch |
| Bolt hole PCD clutch pres.plte | 358.8 mm |
| Number of teeth, starter ring gear | 152 |
| Ring Gear Number | L-01180-0909-00 |
| Crank To Friction Surface | 1.5059 inch |
| Crank To Friction Surface | 38.25 mm |
| Flywheel Friction Surface Inner diameter | 7.7953 inch |
| Flywheel Friction Surface Inner diameter | 198 mm |
| Number of mounting bores | 24 |
| Crank Hole Dia. | 0.5512 inch |
| Crank Hole Dia. | 14 mm |
| Overall Casting O.D. | 14.9213 inch |
| Overall Casting O.D. | 379 mm |
| Has Dowel Pins | without Dowel Pins |
| Ring Gear Major Dia. | 15.349 inch |
| Ring Gear Major Dia. | 389.865 mm |
| Bolt Hole Pattern | 3 |
| Centering diameter / dowel hole | 13.5827 inch |
| Centering diameter / dowel hole | 345 mm |
Additional Information
| Remanufactured Part | N |
| Warranty Special | 12 Months or 12,000 miles, Whichever comes first |
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (HTS) | 8483508080 |
| Stock Status | S |
| UPC | 00670774200915 |
LUK LFW302 Part Interchanges
| Brand | Part Number |
|---|---|
| LuK | 4160206100 |
| Sachs | NFW7223 |
| Valeo | V2151 |
| Standard Flywheels | 3431, 3433 |
| PERFECTION | 50-2702 |
| OEM Part Number | 4746635, 4882546, 5003640AA, 5015624AA, NA |
| AMS | 167434 |
| NAPA Clutch and Flywheel | 88802 |
| N/A | 4882 546, 5003 640AA, NFW1220 |
LUK LFW302 Fits Vehicles
- Dodge Ram 3500 (1994-2005)
- Dodge Ram 2500 (1994-2005)
LUK LFW302 Manufacturer Information
LuK® is a worldwide leader in manufacturing clutches, power steering pumps, dual-mass flywheels, and self-adjusting clutch and engine components for various vehicle applications. It was founded by brothers George and Wilhelm Schaeffler in 1965. Initially, it was established as a manufacturer of diaphragm spring clutches with a release system. But when it was acquired by Schaeffler Group, a globally known supplier of chassis, engine, and transmission components for automotive and industrial applications, the company has grown immensely. Currently, LuK has research and development centers, offices, and manufacturing plants around the world. It remains steadfast to its commitment to providing only the highest quality clutches and other transmission, steering, suspension, and engine components.
