(888) 312-8812 Login SignupTRAKMOTIVE HO8090 CV Axle Shaft
Tap to view 1 more
$9899
Limited availability at this price!
In Stock
Get it by Monday, Dec 22
TRAKMOTIVE HO8090 Part Description
TRAKMOTIVE HO8090 Specifications
Product Attributes
| ABS Ring Tooth Count | 50 |
| ABS Ring Type | Toothed |
| Abs Tone Ring Included | Yes |
| Axle Bolt Hex Size (mm) | N/A |
| Axle Bolt Length (mm) | N/A |
| Axle Bolt Thread Size | N/A |
| Axle Nut Head Type | Hex |
| Axle Nut Height (in) | 1 |
| Axle Nut Height (mm) | 23 |
| Axle Nut Hex Size (in) | 1.4 |
| Axle Nut Hex Size (mm) | 36 |
| Axle Nut Included | Yes |
| Axle Nut Length (in) | 1.5 |
| Axle Nut Length (mm) | 38 |
| Axle Nut Locking Type | Stake |
| Axle Nut Thread Size | M24x1.5 |
| Boot Material | Neoprene |
| Inboard Bolt Head Size (in) | N/A |
| Inboard Bolt Head Size (mm) | N/A |
| Inboard Bolt Head Type | N/A |
| Inboard Bolt Length (in) | N/A |
| Inboard Bolt Length (mm) | N/A |
| Inboard Bolt Thread Size | N/A |
| Inboard Joint Type | Male |
| Inboard Shaft Connection Style | Male |
| New Or Remanufactured | New |
| Number of Bolt Holes | 0 |
| Number Of Inboard Joint Bolt Holes | 0 |
| Number Of Inboard Shaft Bolts | 0 |
| Number Of Inboard Splines | 27 |
| Number Of Outboard Joint Bolt Holes | 0 |
| Number Of Outboard Shaft Bolts | 0 |
| Number Of Outboard Splines | 28 |
| Outboard Bolt Head Size (in) | N/A |
| Outboard Bolt Head Size (mm) | N/A |
| Outboard Bolt Head Type | N/A |
| Outboard Bolt Length (in) | N/A |
| Outboard Bolt Length (mm) | N/A |
| Outboard Joint Bolt Thread Size | N/A |
| Outboard Joint Type | Conventional |
| Outboard Shaft Connection Style | Conventional |
| Overall Compressed Length (in) | 38.5 |
| Overall Compressed Length (mm) | 978 |
| Axle Nut Socket Size | 36 |
| Grade Type | Premium |
| Inboard Joint Boot Material | Neoprene |
| Outboard Joint Boot Material | Neoprene |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708508500 |
| UPC | 00844084040909 |
TRAKMOTIVE HO8090 Part Interchanges
| Brand | Part Number |
|---|---|
| ARC | 80-3087, 80-3126 |
| EMPI | 80-3126 |
| Car Components Technologies (CCT) | 8043 |
| Mevotech | CV6302 |
| Carquest | 410744, 800744 |
| USA Industries | 7028409, AX-2840, AX-28409 |
| Prestige Autotech | 1585, 1587 |
| American Remanufactured | 40-18097S |
| Diversified Shafts Solutions | 39701N |
| Drive Tech America | HO-8097, HO-8097A |
| Fenwick | CV1265 |
| CARDONE Reman | 60-4090, 60-4091, 66-4090, MP4090 |
| IMC | 40721029 |
| OEM Part Number | 44011SV1A10, 44011SV1A60, 44011SV1C10, 44011SV1C60, 44011SV1N00, 44011SV1N01, 44011SV1N50, 44011SV1N51, 44011SV4N50, 44011SV4N51 |
| ODM | HO-8-8525A |
| TrakMotive | HO-8090 |
| ProTech | HO10004 |
| N/A | 410744, NCV36511, 91503, 189090 |
TRAKMOTIVE HO8090 Fits Vehicles
- Honda Accord (1994-1997)
- Acura CL (1997-1999)
TRAKMOTIVE HO8090 Cross References
We have 1 alternatives for the HO8090 by TRAKMOTIVE:
TRAKMOTIVE HO8090 Customer Reviews
No reviews yet
Be the first to review this product!
